GLT - Green Lift Traction
Italian engineering, machine room-less, built to last — by GMV S.p.A., Italy.
Italian engineering, machine room-less, built to last — by GMV S.p.A., Italy.
Brisk Elevators supplies, installs and commissions the Green Lift Traction (GLT) range fromGMV S.p.A., Italy — a lift maker founded in 1958 and one of the world's largest producers of lift hydraulic components.
A gearless MRL rope lift engineered for smoother rides, longer rope life and safer service.
GLT is an MRL rope lift. A gearless permanent-magnet synchronous machine sits at the top of the shaft, fixed to the guide rails, and drives the car in a 2:1 roping arrangement. It uses 120 mm pulleys with polyurethane-coated ropes. All electrical equipment sits outside the shaft in a slim cabinet above the landing door, so technicians can service and rescue safely from the landing.
The full drive fits inside the shaft.
The counterweight, arch and motor pulleys are aligned so ropes do not twist — giving a smoother ride and longer rope life.
Gentle acceleration and precise floor levelling.
Fits new and existing shafts with a wide range of finishes.
2- or 3-panel telescopic, or 4-panel centre opening.
Versions for renovations and older buildings.
Gearless PMSM motor and LED cabin lighting with standby mode.
Extended warranty of up to 10 years and 30 years of spare parts availability.
EN 81-20; low-pit and low-headroom versions to EN 81-21.
UPS-backed return to the nearest floor with doors opening during a power cut.
Allows safe manual movement of the car during emergencies when needed.
Tested to EN 81-58 — E120, EI 30 to EI 120 ratings.
Built to EN 81-20; low-pit and low-headroom versions to EN 81-21.
| Model | Capacity | Entrances | Min. headroom | Min. pit | Best for |
|---|---|---|---|---|---|
| GLT Omega Evo Classic | 350 – 1250 kg (4 – 16 persons) | 1 or 2 opposite | 2500 – 3400 mm | 450 – 1000 mm | New buildings needing premium finishes |
| GLT Omega Evo Smart | 350 – 1000 kg (4 – 13 persons) | 1 or 2 opposite | 2600 – 3400 mm | 480 – 1000 mm | Value-focused new buildings |
| GLT Omega Extra Slim | 350 – 1000 kg (4 – 13 persons) | 1 or 2 opposite | 2600 – 3400 mm | 480 – 1000 mm | Renovations and narrow shafts |
| GLT Sigma Slim | 350 – 630 kg (4 – 8 persons) | 1, 2 opposite or 2 adjacent | 2500 – 3350 mm | 260 – 1000 mm | Stairwells and external steel structures |
| Parameter | Specification |
|---|---|
| Drive | Gearless 3-phase PMSM, VVVF with encoder |
| Roping | 2:1, polyurethane-coated ropes, 120 mm pulleys |
| Rated speed | 1.0 m/s |
| Maximum travel | 45 m |
| Maximum stops | 15 |
| Machine room | Not required |
| Shaft type | Reinforced concrete, brick or steel structure |
| Standards | EN 81-20 / EN 81-21, EU Lift Directive 2014/33/EU |
Source: GMV – Electric Lifts, GMV GLT product page.
